High performance
Supports three-phase unbalanced output, fast STS switching, high PV input and 200A-class charging and discharging.
All-in-one ESS Solution
Ener Hexon® Solution 239P
A 100kW, 239kWh indoor all-in-one energy-storage system integrating hybrid power conversion, BMS, EMS, air-cooled battery storage and precision fire protection.
100kWNominal power
239kWhBattery capacity
IP20Protection
Smart management
Cloud and local monitoring, tariff-based charging, generator control and remote power management.
Parallel expansion
System capacity can be expanded through parallel connections up to four units.
Ener Hexon® Solution 239P
Megatank Energy Storage
High-capacity indoor ESS for commercial and industrial sites.
Ener Hexon® Solution 239P integrates a hybrid inverter, BMS, EMS, air-cooled high-voltage battery pack, intelligent temperature control and combined fire protection. It supports grid, generator and PV integration, rapid switching and parallel expansion.
High performance
Supports three-phase unbalanced output, fast STS switching, high PV input and 200A-class charging and discharging.
Smart management
Cloud and local monitoring, tariff-based charging, generator control and remote power management.
Parallel expansion
System capacity can be expanded through parallel connections up to four units.
Flexible PV integration
Supports DC coupling, AC coupling and multiple PV access methods.
Rapid installation
Cabinet-style prefabrication supports efficient installation and operation.
Layered protection
BMS, EMS and PCS interlocking, temperature detection and electrical protection support safe operation.
Designed forIndoor backup power, micro-grid and high-demand commercial or industrial applications
Ener Hexon® Solution 239P
Technical specifications
Specifications are grouped for faster scanning on desktop and mobile.
System Parameters
- Nominal output power
- 100kW
- Battery capacity
- 239kWh; optional 253kWh or 267kWh
- Battery type
- LiFePO4
- IP protection
- IP20
- Operating temperature
- Charge: 0–45°C; Discharge: -20–45°C
- Storage temperature
- 0–35°C
- Humidity
- 10–85%RH, non-condensing
- Operating altitude
- <3000m; derating above 2000m
Hybrid Inverter
- Model
- YT-IDIT200-PV100-B01 / B02
- Maximum PV input power
- 180kW; optional maximum 240kW
- Starting voltage
- 200V
- MPPT voltage range
- 200–660VDC
- Maximum PV open-circuit voltage
- 660V protected
- MPPT quantity
- 3; optional 4
- Maximum input current
- 160A×3; optional ×4
AC Input – Grid
- Input apparent power
- 200kVA
- Rated voltage
- 3L/N/PE, 220/380V or 230/400V
- Rated frequency
- 50 / 60Hz
- Voltage deviation
- -15% to +15%
- Maximum input current
- 350A
AC Input – Generator
- Input apparent power
- 100kVA
- Maximum input current
- 152A
AC Output
- On-grid / off-grid rated power
- 100kW
- On-grid / off-grid apparent power
- 115kW
- Rated voltage
- 3L/N/PE, 220/380V or 230/400V
- Rated frequency
- 50 / 60Hz
- On-grid rated current
- 151.9A / 144.3A
- Power factor
- 0.99
- On-grid THDi
- <2% with linear load
- Off-grid THDu
- <3%
- Switching time
- <20ms with STS; <3s without STS
- Maximum efficiency
- 98.5%
Protection
- Surge protection
- DC Type II / AC Type II
General
- Maximum unbalanced load
- 100%
- Maximum power per phase
- 33kW
- Cooling
- Intelligent fan cooling
- Communication
- RS485, CAN, Ethernet, 4G
Battery
- Cell capacity
- LFP 3.2V / 314Ah
- Module rated voltage / energy
- 44.8VDC / 14kWh
- Module quantity
- 17S; optional 18S or 19S
- Total rated voltage
- 761.6VDC
- Total rated energy
- 239kWh; optional 253kWh or 267kWh
- Working voltage range
- 666.4–856.8VDC
- Charge / discharge current
- 157A, 0.5C
- Cycle life
- ≥6000 at 25°C, 0.5C / 0.5C, EOL70%
- Certifications
- GB/T 34131, UL1973, UL9540A, IEC62619, UN38.4
Application Scenarios
Recommended applications and deployment scenarios
Backup Power
Integrates grid, generator, PV, battery and site EMS to maintain critical loads.
Micro-grid
Supports local energy generation, storage, distribution and controlled loads.
Commercial and Industrial ESS
Supports self-consumption, peak management, multiple energy sources and system expansion.
Product Resources
Download the Megatank general product catalogue
This model is included in the supplied Megatank general catalogue. A model-specific brochure can replace this download from the Media & Downloads tab at any time.
